NEOFLOOR SLT - Self levelling Epoxy Top Coat

PRODUCT DESCRIPTION

A four component, self levelling floor topping, NEO FLOOR SLT is based on pure liquid epoxy resin cured with a modified cyclo-aliphatic amine curing agent. The system is supplied in pre weighed packs, ready to mix and use, which provides a hard wearing, chemical resistant, impervious and easy to clean seamless flooring. The kit consists of resin, hardener, colour concentrate and formulated aggregates, yielding 0.46 sq. m/kg area @ 2mm thickness or 0.62 sq. m/kg @ 1mm thickness.

Uses

NEO FLOOR SLT is recommended for floor toppings in food, pharma, health care, parking areas, automotive, breweries, decorative flooring etc. NEO FLOOR SLT is recommended for 1mm & 2mm thick systems in kitconsistso.

Key features

·         Excellent adhesion

·         Excellent self levelling properties

·         Excellent chemical resistance

·         Good abrasion resistance

Properties

Type                          : Epoxy-cycloaliphatic amine

Mixing ratio              : Pre-weighed packs with resin, hardener, aggregates and colour   Concentrate

Finish                        : Smooth glossy

Colour                      : Desired shade

Pot life @ 270C

ASTM D 2471           : 40 – 45 min

Theoretical Covering Capacity

0.62 sq.mtr./ kg @ 1 mm DFT

0.46 sq.mtr/ kg @ 2 mm DFT

Recommended WFT

ASTM D 4414 / ASTM D 1186

SLT 1000               : 1000 microns

SLT 2000              :  2000 microns

 Drying time ASTM D 1640

Surface dry         : 1 – 2 hrs @ 30 ‘ C

Tack free dry     :  5 – 6 hrs @ 30 ‘ C

Hard dry           :  13 - 14 hrs @ 30 ‘ C

Full cure            :  7 days @ 30 ‘ C

Application        : Leveller and spike roller Recommended thinner

Clean up           : ET - 505

Shelf life            : 12 months in the un-opened container

Performance data

Compressive strength

ASTM D 695        : 50 – 55 MPa

Tensile strength

ASTM D 638      : 10 – 15 MPa

Elongation

ASTM D 638      : 2 – 3 %

Flexural strength

ASTM D 790      : 20 – 25 MPa

Abrasion resistance

ASTM D 4060    : 65 - 70 mg loss

Chemical resistance

Excellent resistance is observed against distilled water, detergent solutions, alkalis and acids.

Chemical spillages should always be wiped up as quickly as possible and not be allowed to concentrate up by evaporation. The data on the list of the chemicals found resistant to this product during our lab study is available on request.

Directions to use

Before primer application, CDS (Clean, Dry and Sound) test is conducted on the concrete. Moisture test is conducted by moisture meter or plastic sheet method (ASTM D4263: Standard test method for indicating moisture in concrete). The residual moisture should not be more than 4-5%. Surface preparation like scarification, grinding or shot blasting is done to achieve a surface profile of 150-200 microns. Apply NEO FLOOR P as prime coat. Allow to cure for 5-6 hours. Ensure that the surface is free from all porosities.

Mix NEO FLOOR SLT resin and hardener in the pre weighed ratio. Agitate the mixture by an electrically driven motor. Add NEO TINT Colour (colour concentrate) and formulated aggregates under stirring. Lay the mixture to the desired thickness. De-aerate by using spike rollers. Allow to cure for a minimum 48 hours before the trafficking is commenced.

Packaging

NEO FLOOR SLT is available in pre-weighed kits and has a maximum shelf life of 12 months in the un- opened containers.

Storage and handling

The product should be stored in accordance with national regulations. It should be kept in a cool, well-ventilated area, away from heat, direct sunlight, sparks and children. Handle with care. Mix resin and hardener as per the ratio. Use the mix solution within the pot life time

Technical Support

NEO offers full technical support package to specifies, contractors and end users, as well as technical assistance on site and after sales consultation

Specialnote

The data given is for guideline only. The physical values are subject to normal manufacturing tolerances, colour and testing variances. The coverage & consumption figures are theoretical and do not allow for any additional material required due to surface porosity, surface profile, variations in level or wastage etc. The actual drying time/ overcoat interval may be shorter or longer, depending on film thickness, ventilation, humidity, temperature etc. The information provided above is at 30°C and 65relative.humidity.
